SPECIFICATIONS AND CHARACTERISTICS:
|
· Volts & Cover Color |
· ANSI C136.10 & UL773 Standard . Rated Load:
|
· Gray standard for 120VAC
· Blue standard for 120-277VAC (105-305VAC)
· Turn-ON LightLevel: 10-16 Lux
· Turn ON/OFF Ratio: 1:1.5 to4
· Time Delay: 3-15 sec
· Operating Temperature: -40'C to +70C
· MOV Surge Protection:90/190J/380J(10/1000us)
· Energy Consumption: Less than 1Watt (120V<0.5W)
· Electrical Life: >5000 cycles
· Sensor Type: Silicon Photocell
· Housing: UV stabilized PC
· Failure Mode: Fail ON
· Size: 80mm
· ANSI C136.10 & UL773 Standard
· UL Listed. Reference No.: E178670
. Rated Load:
| Code | Voltage | Ballast |
| 10LED | 120V | 8.3A (HID) |
| 120V | 8A (LED) | |
| 208-277V | 3.6A (HID) | |
| 208-277V | 3A (LED) |
